Ai DigiM 10L Heating Stirring Mantle, PID Controller
$1,190
$1,096
and up
| SKU | Description | Capacity | Temperature Range | Speed Range | Electrical | Quantity | Price | Add to Cart |
|---|---|---|---|---|---|---|---|---|
| DIGIM10.110 | Ai DigiM Heating Stirring Mantle, PID Controller | 10 L | Ambient to 300 °C | up to 2000 rpm | 110V, 60Hz, 1-Ph, 2050W, 24A | 1 Each |
|
|
| DIGIM10-UL.110 | Ai DigiM Heating Stirring Mantle, PID Controller | 10 L | Ambient to 300 °C | up to 2000 rpm | 110V, 60Hz, 1-Ph, 2050W, 24A, UL/CSA Certified | 1 Each |
|
|
| DIGIM10.220 | Ai DigiM Heating Stirring Mantle, PID Controller | 10 L | Ambient to 300°C | up to 2000 rpm | 220V, 50/60Hz, 1-Ph, 2050W, 12A | 1 Each |
|
|
| DIGIM10-UL.220 | Ai DigiM Heating Stirring Mantle, PID Controller | 10 L | Ambient to 300 °C | up to 2000 rpm | 220V, 50/60Hz, 1-Ph, 2050W, 12A, UL/CSA Certified | 1 Each |
|
Description
The Ai DigiM heating and stirring mantles come standard with digital display for the most accurate control. The large display interface makes it easy to quickly and precisely adjust temperature and rotation speeds.
The DigiM mantle is equipped with two sets of thermocouples for proper temperature and speed detection. The heating jacket is pre-treated before shipment, which ensures that no smoke or odors (caused by heat) are released into your work environment.
Package Includes:
- Ai DigiM 10L digital heating & stirring mantle (1 each)
- External temperature probe (1 each)
- Internal temperature plug (1 each)
- Boss head clamp (2 each)
- Stainless steel support rod, 15 inches (2 each)
- PTFE coated stir bar (2 each)
- PTFE coated magnetic stir bar remover (1 each)
- 4 prong stainless steel clamp, opens to 3 1/2" (2 each)
- User Manual (1 each)
Specifications
| Model | DigiM10 |
|---|---|
| Electrical | 110V 60Hz 1-Phase, 2050 watts, 24A or 220V 50/60Hz 1-Phase, 2050 watts, 12A |
| Temperature Range | Ambient to 300°C |
| Stirring | Maximum speed: 2000 rpm Motor power: 40 watts Motor type: brushless DC motor |
| Controller | PID control with digital temperature and rotation speed display |
| External Thermocouple | Type: PT100 Cable length: 43 inches Stainless steel probe length: 15 inches Stainless steel probe diameter: 5 mm |
| Flask holder | Maximum flask capacity: 10 liters Top opening diameter: 11.75 inches Depth: 6.5 inches |
| Dimensions (WxDxH) | Unit: 18 x 17.5 x 13 inches, Shipping: 22 x 21 x 18 inches |
| Weight | Unit: 30 lbs, Shipping: 40 lbs |
| Safety | Thermocouple failure protection |
| Certification | UL/CSA (optional) |
| Warranty | One Year |
