SHEL LAB vacuum ovens provide exceptional capabilities for fast and gentle drying of heat-sensitive materials. They prevent residue accumulation on products and allow safe drying of materials at lower temperatures than typically required when using convection ovens.These units feature a radiant heating system that optimizes chamber space and provides excellent heat transfer and temperature uniformity. All SHEL LAB vacuum ovens are built with stainless steel chambers that are easy to clean and have exceptional durability. The doors on these units have positive latch handles with spring-loaded glass to facilitate a good vacuum seal without hinge binds that shorten the gasket life. The tempered glass viewing window allows for safe, continuous monitoring of samples. A selection of gaskets (for specific applications) and a small benchtop footprint increase the versatility of these ovens.
The SHEL LAB economy series of vacuum ovens are outstanding in any application.
Features
- Analog Temperature Control
- Stainless-Steel Interior
- Built-in Overtemperature Protection
- 24 Month Limited Warranty
Specifications
| Model |
SVAC1E |
| Exterior Dimensions (W × D × H) |
15.5" × 19" × 22.5" |
| Interior Dimensions (W × D × H) |
9" × 12" × 9" |
| Volume |
0.56 cu. ft. |
| Shelf Dimensions |
8.5" × 11.0" |
| Unit Weight |
59.4 lbs |
| Interior Metal |
300 Stainless Steel |
| Exterior Metal |
Painted Cold Roll Steel |
| Operating Temperature Range |
Amb +15°C - 210°C |
| Temperature Uniformity - Midrange |
9.0 °C |
| Temperature Stability - Midrange |
0.5 °C |
| Controller Type |
Analog |
| Power Voltage, Frequency |
110-120 VAC, 50/60 Hz, 5.0 Amps (NON CE) |
Documentation
