VELP OHS Series Digital Overhead Stirrers
- Support Stand, Clamp and Stirring Shaft sold separately.
Image | SKU | Description | Volume Maximum | Speed | Viscosity Maximum | Electrical | Quantity | Price | Add to Cart |
---|---|---|---|---|---|---|---|---|---|
|
F20110490 | OHS 200 Digital Overhead Stirrer | Up to 100 L | 6-400 rpm | 30-2000 rpm | 100,000 mPa·s | 115V / 60Hz | 1 Each | $3,113 | |
|
F20110491 | OHS 100 Digital Overhead Stirrer | Up to 100 L | 30-1300 rpm | 70,000 mPa·s | 115V / 60Hz | 1 Each | $2,365 | |
|
F20110492 | OHS 60 Digital Overhead Stirrer | Up to 40 L | 30-2000 rpm | 50,000 mPa·s | 115V / 60Hz | 1 Each | $1,763 | |
|
F20110493 | OHS 40 Digital Overhead Stirrer | Up to 25 L | 30-2000 rpm | 25,000 mPa·s | 115V / 60Hz | 1 Each | $1,459 | |
|
F20110494 | OHS 20 Digital Overhead Stirrer | Up to 25 L | 30-2000 rpm | 10,000 mPa·s | 115V / 60Hz | 1 Each | $1,319 |
Description
Safety and resistance for your lab
OHS Series Digital Overhead Stirrers are designed to guarantee the highest safety standards. The resistant sealed housing and the IP 54 Protection Rating guarantee durability even in the most aggressive environments.
- Integrated overload, overtemperature, and overcurrent safety alarms will preserve the performance over time and stop stirring for maximum safety in your lab.
- Safe start and stop knob operation and lock key avoid unintended stat up and changes of the working conditions.
OHS Series Digital Overhead Stirrers ensures continuous operation and is backed by 3 Years Warranty extension.
Best-in-class Stirring Power
The OHS Series Digital Overhead Stirrers are the ideal solution for demanding applications operating with high viscosities. The electronic controlled brushless motor of the OHS Series Digital Overhead Stirrers ensure the longest lifespan.
SpeedServoTM torque compensation technology keeps the speed constant automatically adjusting to viscosity changes.
It provides the best performance for both high torque and high volume operations:
Constant torque at any speed
The brushless motor and the microprocessor guarantee excellent performance marking the difference between a conventional overhead and the VELP OHS Series.
The torque is stable throughout the whole speed range, ensuring stirring at maximum torque even at the highest speed.
This is a very important parameter for the reproducibility of your tests.
SmartChuck™ simplifies shaft accommodation
The OHS Advance SmartChuck™ technology simplifies the shaft accommodation process that can be carried out even with one hand and does not require any tool, making your life easier.
With two simple operations, you can unlock the protection ring to drive the shaft in and out with maximum ease.
The opening of the ring during the stirring process will automatically block the analysis and the instrument informs you for maximum safety.
Easy-to-use and precise
All the necessary information are available at a glance and the dedicated Torque Display with 4 LED segments informs about viscosity changes during the operation.
The OHS Digital integrated timer allows unattended operations. Program your OHS Digital from 1min to 99.59h and walk away!
USB interface facilitates software updates if required.
Specifications
Model | OHS 200 | OHS 100 | OHS 60 | OHS 40 | OHS 20 |
---|---|---|---|---|---|
Display | Digital Display | Digital Display | Digital Display | Digital Display | Digital Display |
User Interface | Digital | Digital | Digital | Digital | Digital |
Motor | Brushless DC | Brushless DC | Brushless DC | Brushless DC | Brushless DC |
Stirring Volume (H2O) | Up to 100 L | Up to 100 L | Up to 40 L | Up to 25 L | Up to 25 L |
Speed Gears | 2 | 1 | 1 | 1 | 1 |
Max Torque | 200 Ncm | 100 Ncm | 60 Ncm | 40 Ncm | 20 Ncm |
Stirring Speed Range | 6-400 rpm 30-2000 rpm |
30-1300 rpm | 30-2000 rpm | 30-2000 rpm | 30-2000 rpm |
Speed Setting Resolution | 1 rpm | 1 rpm | 1 rpm | 1 rpm | 1 rpm |
Speed Control | Digital | Digital | Digital | Digital | Digital |
Max Viscosity | 100.000 mPa*s | 70.000 mPa*s | 50.000 mPa*s | 25.000 mPa*s | 10.000 mPa*s |
Torque Compensation | SpeedServo™ | SpeedServo™ | SpeedServo™ | SpeedServo™ | SpeedServo™ |
Chuck Range | Ø from 1 to 13 mm | Ø from 1 to 13 mm | Ø from 1 to 13 mm | Ø from 1 to 13 mm | Ø from 1 to 13 mm |
Shaft Diameter Pass-Through | up to 8.5mm | up to 8.5mm | up to 8.5mm | up to 8.5mm | up to 8.5mm |
Timer | Yes | Yes | Yes | Yes | Yes |
Lock of the Instrument | Yes | Yes | Yes | Yes | Yes |
Interfaces | USB | USB | USB | USB | USB |
Dimensions | 90 x 315 x 235 mm | (3.5 x 12.4 x 9.3 in) | 90 x 315 x 235 mm | (3.5 x 12.4 x 9.3 in) | 90 x 285 x 235 mm | (3.5 x 11.2 x 9.3 in) | 90 x 285 x 235 mm | (3.5 x 11.2 x 9.3 in) | 90 x 285 x 235 mm | (3.5 x 11.2 x 9.3 in) |
Weight | 4.6 kg | 10.1 lbs | 4.1 kg | 9 lbs | 4.1 kg | 9 lbs | 4.1 kg | 9 lbs | 4.1 kg | 9 lbs |
Protection Class | DIN EN 60529 IP 54 | DIN EN 60529 IP 54 | DIN EN 60529 IP 54 | DIN EN 60529 IP 54 | DIN EN 60529 IP 54 |
Documentation
Product Data Sheets |
---|
OHS Series Overhead Stirrer Product Data Sheet |
OHS Advance Instruction Manual |
