Julabo DYNEO™ DD Refrigerated/Heating Circulators
Julabo DYNEO™ DD Refrigerated/Heating Circulators
Julabo DYNEO™ DD Refrigerated/Heating Circulators Julabo DYNEO™ DD Refrigerated/Heating Circulators
FREE SHIPPING

Julabo DYNEO™ DD Refrigerated/Heating Circulators, -20 to 200°C

Questions? Quotes? Let's chat!
$8,014
$7,212 and up
Image SKU Description Filling Volume Temperature Range Temperature Stability Interface Electrical Quantity Price Add to Cart
products/dyneo_dd_200f_1_94e8946b-8a9c-48f7-9dff-edea7fe7b2c5.jpg
9021701.02 DYNEO Refrigerated/Heating Circulator DD-200F 4 L -20 to 200°C ±0.01°C USB 115V, 60Hz 1 Each
$8,014
$7,212
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_200f_1_8de25912-ba43-49c5-acac-a134bf25da6d.jpg
9021701.02.D DYNEO Refrigerated/Heating Circulator DD-200F 4 L -20 to 200°C ±0.01°C RS232 115V, 60Hz 1 Each
$8,465
$7,618
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_200f_1_25c52837-4b1c-4ef4-94a3-e07999c62e92.jpg
9021701.02.A DYNEO Refrigerated/Heating Circulator DD-200F 4 L -20 to 200°C ±0.01°C Analog 115V, 60Hz 1 Each
$8,728
$7,855
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_300f_1.jpg
9021703.02 DYNEO Refrigerated/Heating Circulator DD-300F 4 L -25 to 200°C ±0.01°C USB 115V, 60Hz 1 Each
$8,977
$8,079
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_300f_1_026afbcb-7985-40e4-a937-1a501c88cf30.jpg
9021703.02.D DYNEO Refrigerated/Heating Circulator DD-300F 4 L -25 to 200°C ±0.01°C RS232 115V, 60Hz 1 Each
$9,413
$8,471
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_300f_1_4bd8dbf8-f7cd-4f42-bc3a-e7a266b76f4a.jpg
9021703.02.A DYNEO Refrigerated/Heating Circulator DD-300F 4 L -25 to 200°C ±0.01°C Analog 115V, 60Hz 1 Each
$9,676
$8,708
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_600f_1_44042e1f-5b83-4206-a00b-20babaf3af10.jpg
9021704.02 DYNEO Refrigerated/Heating Circulator DD-600F 7.5 L -35 to 200°C ±0.01°C USB 115V, 60Hz 1 Each
$10,019
$9,017
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_600f_1_ca0bb90b-b2b5-41a6-86bd-e82d21cd9d2e.jpg
9021704.02.D DYNEO Refrigerated/Heating Circulator DD-600F 7.5 L -35 to 200°C ±0.01°C RS232 115V, 60Hz 1 Each
$10,413
$9,371
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_600f_1_a2cd7515-e6c2-41cc-8629-ddb6f6ba56b3.jpg
9021704.02.A DYNEO Refrigerated/Heating Circulator DD-600F 7.5 L -35 to 200°C ±0.01°C Analog 115V, 60Hz 1 Each
$10,661
$9,594
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_601f_1_eafa58e3-ff28-4bdd-a745-061673fed3ee.jpg
9021705.02 DYNEO Refrigerated/Heating Circulator DD-601F 10 L -35 to 200°C ±0.01°C USB 115V, 60Hz 1 Each
$10,183
$8,825
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_601f_1_3b575b38-4a55-4b74-86c9-af394b663087.jpg
9021705.02.D DYNEO Refrigerated/Heating Circulator DD-601F 10 L -35 to 200°C ±0.01°C RS232 115V, 60Hz 1 Each
$10,587
$9,175
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_601f_1_a7b15d94-1be4-4514-a420-b0790b8dd8a3.jpg
9021705.02.A DYNEO Refrigerated/Heating Circulator DD-601F 10 L -35 to 200°C ±0.01°C Analog 115V, 60Hz 1 Each
$10,828
$9,384
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_1000f_1_61a78816-09b1-45d1-8715-6dd575ed00ed.jpg
9021707.02 DYNEO Refrigerated/Heating Circulator DD-1000F 7.5 L -50 to 200°C ±0.01°C USB 115V, 60Hz 1 Each
$13,960
$12,564
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_1000f_1_d864cfee-9094-4b26-a78d-2ee3f8b51c82.jpg
9021707.02.D DYNEO Refrigerated/Heating Circulator DD-1000F 7.5 L -50 to 200°C ±0.01°C RS232 115V, 60Hz 1 Each
$14,418
$12,976
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...
products/dyneo_dd_1000f_1_6bc12ec6-6977-4dab-a45b-4182ed978da6.jpg
9021707.02.A DYNEO Refrigerated/Heating Circulator DD-1000F 7.5 L -50 to 200°C ±0.01°C Analog 115V, 60Hz 1 Each
$14,681
$13,212
  • 1
  • 2
  • 3
  • 4
  • 5
Custom...

Description

DYNEO DD refrigerated circulators have a wide working temperature range. Refrigerated circulators are suitable for both internal and external applications. The multilingual 3.5-inch color display and unique rotary knob provide for straightforward and intuitive operation. Pump capacity is 22 l/min with pressure of 0.6 bar. The cooling machines operate precisely and reliably even at elevated ambient temperatures up to +40 °C.

Features

  • Powerful cooling machines
  • Suitable for internal and external applications
  • Optimized cooling coil design saves space in the bath tank
  • Powerful and infinitely adjustable pressure pump
  • Flow rate 22 l/min, pressure 0.6 bar
  • Easy switching between internal and external circulation
  • Large color TFT display, multilingual interface
  • Central rotary knob (controller) simplifies operation
  • Integrated programmer
  • Integrated external Pt100 connection
  • USB port
  • RS232 interface or analog interfaces (optional)
  • Bath cover included with delivery
  • Integrated drain makes emptying liquid easy and safe.

Specifications

DYNEO MODEL DD-200F DD-201F DD-300F DD-600F DD-601F DD-900F DD-1000F DD-1001F
Working Temperature Range -20 to +200°C -30 to +200°C -35 to +200°C -38 to +200°C -50 to +200°C -38 to +100°C
Temperature Stability ±0.01°C
Heating Capacity 2 kW
Cooling Capacity at 20°C 0.22 kW 0.31 kW 0.6 kW 0.9 kW 1 kW
Pump Flow Rate 22 l/min
Pump Capacity 0.6 bar (pressure)
External PT100 Sensor Connection Yes
Bath Opening/Bath Depth W×L/D 13cm × 15cm / 15cm 22cm × 15cm / 15cm 22cm × 15cm / 20cm 26cm × 35cm / 20cm 18cm × 13cm / 15cm 35cm × 41cm / 30cm
Filling Volume 3 to 4 Liters 5 to 7.5 Liters 8 to 10 Liters 21 to 30 Liters 5 to 7.5 Liters 42 to 56 Liters
Product Data Sheets
Julabo DYNEO Brochure
